- 4 - 20 mA output signal

- Operating temperature -40 to 85° C

- Measuring range 0 - 600 bar

- Standard pressure connection G 1/4A ISO 228/1

- For use in severe industrial environments such as pumps, compressors, pneumatics and water treatment

- Accuracy +/-0.5% FS

The compact heavy duty pressure transmitter Danfoss MBS 3050 is designed for use in hydraulic applications with severe medium influences like cavitation, liquid hammer or pressure peaks and offers a reliable pressure measurement, even under harsh environmental conditions. The flexible pressure transmitter programme covers a 4-20 mA output signal, absolute and gauge (relative) versions, measuring ranges from 0-1 to 0-600 bar and a wide range of pressure- and electrical connections. Excellent vibration stability, robust construction, and a high degree of EMC/EMI protection equip the pressure transmitter to meet the most stringent industrial requirements.

Features

- Designed for use in severe industrial environments

- Resistant to cavitation, liquid hammer and pressure peaks

- Enslosure and wetted parts of acid-resistant stainless steel (AISI 316L)

- Pressure ranges in relative (gauge) or absolute from 0 up to 600 bar

- All standard output signals: 4 - 20 mA, 0 - 5 V, 1 - 5 V, 1 - 6 V, 0 - 10 V, 1 - 10 V

- A wide range of pressure and electrical connections

- Temperature compensated and laser calibrated

Approvals

Danfoss-foss - EU Declaration Pressure transmitter, MBS 32;MBS 32R;MBS 33;MBS 33M;MBS 2050;MBS 2100;MBS 2150;MBS 2250;MBS 3000;MBS 3050;MBS 3100;MBS 3150; MBS 3200;MBS 3250;MBS 3300;MBS 3350;MBS 4010;MBS 4050;MBS 4500;MBS 4510;MBS 5050;MBS 5100;MBS 5150;MBS 5153 Danfoss-foss - Danfoss Pressure transmitter, MBS Danfoss-foss - Danfoss Pressure transmitter, MBS
