- 4 - 20 mA output signal

- Operating temperature -40 to 85° C

- Measuring range 0 - 600 bar

- Standard pressure connection G 1/4A ISO 228/1

- For use in severe industrial environments such as pumps, compressors, pneumatics and water treatment

- Accuracy +/-0.5% FS

The Danfoss ship approved high accuracy pressure transmitter MBS 5100 is designed for use in almost all marine applications, and offers a reliable pressure measurement, even under harsh environmental conditions. The pressure transmitter programme in block design is approved according to LR, DNV, GL, RINA, ABS, BV, NKK, PRS, MRS, KRS requirements, and covers a 4-20 mA output signal, absolute and gauge (relative) versions, measuring ranges from 0-1 to 0-600 bar, zero point and span adjustment, plug connection and female/flange pressure connections. Excellent vibration stability, robust construction, a high degree of EMC/EMI protection and a high operating temperature, equip the pressure transmitter to meet the most stringent industrial requirements.

Features

- Designed for use in severe industrial environments

- Resistant to cavitation, liquid hammer and pressure peaks

- Enslosure and wetted parts of acid-resistant stainless steel (AISI 316L)

- Pressure ranges in relative (gauge) or absolute from 0 up to 600 bar

- All standard output signals: 4 - 20 mA, 0 - 5 V, 1 - 5 V, 1 - 6 V, 0 - 10 V, 1 - 10 V

- A wide range of pressure and electrical connections

- Temperature compensated and laser calibrated

Approvals

ABS-American Bureau of Shipping Pressure transmitter, MBS 5100

ABS-American Bureau of Shipping Pressure switch, MBC 5100

ABS-American Bureau of Shipping Pressure transmitter, MBS 5100

BV-Bureau Veritas Pressure transmitter, MBS 5100;MBS 5150

Danfoss-foss - Danfoss Pressure transmitter, MBS

Danfoss-foss - EU Declaration Pressure transmitter, MBS 32;MBS 32R;MBS 33;MBS 33M;MBS 2050;MBS

2100;MBS 2150;MBS 2250;MBS 3000;MBS 3050;MBS 3100;MBS 3150; MBS 320

0;MBS 3250;MBS 3300;MBS 3350;MBS 4010;MBS 4050;MBS 4500;MBS 4510;MBS 5050;MBS 5100;MBS 5150;MBS 5153

Danfoss-foss - Danfoss Pressure transmitter, MBS

DNV-Det Norske Veritas Pressure transmitter, MBS 5100;MBS 5103;MBS 5150;MBS 5153

GL-Germanischer Lloyd Pressure transmitter, MBS 5100;MBS 5150

KR-Korean Register of Shipping Pressure transmitter, MBS 5100;MBS 5150

LR-Lloyds Register of Shipping Pressure transmitter, MBS 5100;MBS 5150;MBS 5103;MBS 5153

NKK-Nippon Kaiji Kyokai Pressure transmitter, MBS 5100;MBS 5150;MBS 5103;MBS 5153

NKK-Nippon Kaiji Kyokai Pressure transmitter, MBS 5100;MBS 5150;MBS 5103;MBS 5153

RINA-A - Registro Italiano Navale Pressure transmitter, MBS 5100;MBS 5150

RMRS-S - Russian Maritime Register of Shipping Pressure transmitter, MBS 5100;MBS 5150

RMRS-S - Russian Maritime Register of Shipping Pressure transmitter, MBS 5100;MBS 5150
