- Pressure ranges: -0.2 to 21 bar

- High contact load - Ultra short bounce-time

- Also available with gold plated contact systems

- Media: Gaseous media and air

- Enclosure IP44 when mounted with top cover and back plate

- Also available with enclosure IP55 for OEM customers

- Small dimensions - space saving - easy to install

- Shock and impact resistant

KP features

The contact system in KP pressure switches has a snap function. This means that the bellows is active only when the cut-in or cut-out value is reached. The bellows is connected to the pressure of the controlled plant via the connector.

Approvals

Danfoss-foss - EU Declaration Thermostat, KP Danfoss-foss - Danfoss Pressure controller, KP 1W1;KP 5;KP 5A;KP 11;KP 21;KP 25;KP 15 KP 15A;KP 34;KP 35 KP 36;KP 37;KP 44

Danfoss-foss - Danfoss Pressure controller, KP 1;KP 1A;KP 1E;KP 2;KP 6W;KP 6B;KP 6S KP 6AW;KP 6AB;KP 6AS; KP 7W;KP 7B;KP 7S;KP7 EW;KP 7EB;KP 7ES; KP 7BS;KP 7ABS;KP 17W;KP 17B;KP 17WB

Danfoss-foss - EU Declaration Pressure controller, KP 1;KP 1A;KP 1E;KP 2;KP 6W;KP 6B;KP 6S;KP 6AW;KP 6AB;KP 6AS;KP7W;KP 7B;KP 7S;KP 7EW;KP 7EB;KP 7BS;KP 7ABS;KP 17W;KP 17B;KP 17WB

Danfoss-foss - Danfoss Pressure switch, KP

Danfoss-foss - Danfoss Pressure controller, KPI

Danfoss-foss - EU Declaration Thermostat, KP

DEMKO-KO - UL International Demko A/S Pressure controller, KP 1E

DNV-Det Norske Veritas Pressure switch, KPS 31;KPS 33;KPS 35;KPS 37;KPS 39;KPS 43;KPS 45;KPS 47

FM-Approvals Pressure switch, KP 34;KP 35;KP 36;KP 37

FM-Approvals Pressure switch, KP 34;KP 35;KP 36;KP 37 GL-Germanischer Lloyd Pressure switch, KP 1;KP 1A;KP 2;KP 5;KP 5A;KP 6W;KP 6AW;KP 6B;KP 6AB;KP 6S;KP 6AS;KP 7W;KP 7B;KP 7S;KP 7BS;KP 15;KP 15A;KP 17W;KP 17B

LR-Lloyds Register of Shipping Pressure switch, KPS 31;KPS 33;KPS 35;KPS 37;KPS 39

RINA-A - Registro Italiano Navale Pressure switch, KP

TÜV-Technischer Überwachungs-Verein Pressure switch, KP 1;KP 1A;KP 2;KP 7B;KP 7S;KP 7W;KP 7BS;KP 7ABS;KP 17B;KP 17W;KP 17S

TÜV-Technischer Überwachungs-Verein Pressure switch, KP 1;KP 1A;KP 1E;KP 2;KP 7BS;KP 7ABS;KP 7W;KP 7B;KP 7S;KP 7EW;KP 7EB;KP 7ES;KP 17B;KP 17W;KP 17WB
