- Designed for use in severe industrial environments

- High vibration stability

- Part of the Danfoss block system, consisting of MBC pressure controls, MBS pressure transmitters and MBV test valves

- MBC 5100 with all major ship approvals

- High repeatability

- Optimal compact design for machine building purposes

- Intended for alarm indication, shut down, control and diagnostics in many applications - motors, gears, thrusters, pumps, filters, compressors etc.

- Pressure ranges: -0.2 to 400 bar

- Low differential (fixed) micro switch

- Resistant to shock and vibrations

- Enclosure IP65

- Diaphragm version for applications with pulsations/pressure peaks

- Compact design

- Low installations costs

- Fast and easy to operate

- Easy to mount on block test valve

- Available as differential pressure switch

Danfoss MBC 5100 pressure switches are used in marine applications where space and reliability are the most important features. MBCs are compact pressure switches, designed according to our new block design to survive in the harsh conditions known from machine rooms onboard ships. MBCs have high vibration resistance and feature all commonly marine approvals. The fixed, but low differential guarantees accurate monitoring of critical pressures. MBV test valves can be delivered as standard option for MBC pressure switches. The Danfoss MBC pressure switch is for marine and hydraulic applications and approved by nine major ship authorities.

The MBC 5000 has the following features for the benefit of your application :

Approvals

ABS-American Bureau of Shipping Pressure switch, MBC 5100

BV-Bureau Veritas Pressure switch, MBC 5100;MBC 5100 Wärtsila

BV-Bureau Veritas Pressure switch, MBC 5100;MBC 5100 Wärtsila

CCC-China Cumpulsory Certification Pressure switch, MBC

CCS-China Classification Society Pressure switch, MBC 5100

Danfoss-foss - EU Declaration Pressure controller, MBC

Danfoss-foss - EU Declaration Pressure controller, MBC

Danfoss-foss - EU Declaration Thermostat, MBC

DNV-Det Norske Veritas Pressure switch, MBC 5100

DNV-Det Norske Veritas Pressure switch, MBC 5100

GL-Germanischer Lloyd Pressure switch, MBC 5100

KR-Korean Register of Shipping Pressure switch, MBC 5100

LR-Lloyds Register of Shipping Pressure switch, MBC 5100

NKK-Nippon Kaiji Kyokai Pressure switch, MBC 5100

NKK-Nippon Kaiji Kyokai Pressure switch, MBC 5100

RINA-A - Registro Italiano Navale Pressure switch, MBC 5100

RMRS-S - Russian Maritime Register of Shipping Pressure switch, MBC 5100

RMRS-S - Russian Maritime Register of Shipping Pressure switch, MBC 5100
